Caractéristiques Système
Mémoire système (standard/max) | 4,096 MB |
---|---|
Disque dur standard | 250 GB (standard) |
Interface standard | 10/100/1,000-Base-T Ethernet; USB 2.0; Wi-Fi 802.11b/g/n (optional) |
Protocoles réseaux | TCP/IP (IPv4 / IPv6); IPX/SPX; NetBEUI; AppleTalk (EtherTalk); SMB; LPD; IPP; SNMP; HTTP |
Frame types | Ethernet 802.2; Ethernet 802.3; Ethernet II; Ethernet SNAP |
Chargeur automatique de documents | Up to 300 originals; A6-A3; 35-210 g/m²; Dualscan ADF |
Format papier | A6-SRA3; customised paper sizes; banner paper max. 1,200 x 297 mm |
Grammage papier | 52-300 g/m² |
Capacité papier (standard/max) | 1,150 sheets/6,650 sheets |
Alimentation papier (standard) | 1x 500 sheets; A5-A3; 52-256 g/m²; 1x 500 sheets; A5-SRA3; 52-256 g/m² |
Alimentation papier (en option) | 1x 500 sheets; A5-A3; 52-256 g/m²; 1x 500 sheets; A5-A3; 52-256 g/m²; 1x 2,500 sheets; A4; 52-256 g/m² |
Magasin grande capacité latéral (en option) | 1x 3,000 sheets; A4; 52-256 g/m²; 1x 2,500 sheets; A4-SRA3; 52-256 g/m² |
Passe copie | 150 sheets; A6-SRA3; custom sizes; banner; 60-300 g/m² |
Recto Verso automatique | A5-SRA3; 52-256 g/m² |
Modes de finition (en option) | Offset; group; sort; staple; punch; post insertion; z-fold; centre-fold; letter fold; booklet |
Capacité de sortie (standard) | Max. 250 sheets |
Capacité de sortie (en option) | Max. 3,300 sheets |
Agrafage | Max. 100 sheets or 94 sheets + 2 cover sheets (up to 209 g/m²) |
Capacité de sortie agrafage | Max. 1,000 sheets |
Pli lettre | Max. 3 sheets |
Capacité de sortie pli lettre | Max. 30 sheets; unlimited (without tray) |
Livret | Max. 20 sheets or 19 sheets + 1 cover sheet (up to 209 g/m²) |
Capacité de sortie livret | Max. 100 booklets; unlimited (without tray) |
Volume Copie/impression (mensuel) | Rec. 30,000 pages; Max. 200,000 pages¹ |
Durée de vie du toner | Black up to 28,000 pages; CMY up to 26,000 pages |
Durée de vie de l’unité image | Black up to 140,000/600,000 pages (drum/developer); CMY up to 100,000/600,000 pages (drum/developer) |
Consommation électrique | 220-240 V / 50/60 Hz; Less than 1,6 kW |
Dimension (LxPxH) | 615 x 693 x 961 mm (without options); 615 x 693 x 1,200 mm (with desk/tray) |
Poids | Approx. 110 kg (without options) |
Caractéristiques Impression
Résolution d’impression | 1,800 (equivalent) x 600 dpi; 1,200 x 1,200 dpi |
---|---|
Langage | PCL 6 (XL 3.0); PCL 5c; PostScript 3 (CPSI 3016); XPS |
Système d’exploitation | Windows VISTA (32/64); Windows 7 (32/64); Windows 8 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Windows Server 2016; Macintosh OS 10.x; Unix; Linux; Citrix |
Polices d’impression | 80 PCL Latin; 137 PostScript 3 Emulation Latin |
Fonctions d’impression | Direct print of PCL, PS, TIFF, XPS, PDF (v1.7), encrypted PDF files and OOXML (DOCX, XLSX, PPTX); mixmedia and mixplex; "Easy Set” job programming; overlay; watermark; copy protection; carbon copy print |
Impression mobile | AirPrint (iOS), Mopria (Android), Google Cloud Print (optional), WiFi Direct (optional), Konica Minolta Print Service (Android), PageScope Mobile (iOS, Android, Windows 10 Mobile); Mobile Authentication and Pairing (Android, iOS) |
Caractéristiques Impression (option)
Contrôleur | Embedded Fiery IC-416 |
---|---|
CPU | CPU type @ 2.9 GHz |
Mémoire / Disque Dur | 2,048 MB / 250 GB |
Langage | Adobe PostScript 3 (CPSI 3020) PCL 6, PCL 5c |
Operating systems | Windows VISTA (32/64); Windows 7 (32/64); Windows 8 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Macintosh OS 10.x; Linux |
Caractéristiques Scanner
Vitesse de numérisation (Noir et Blanc/Couleur) | Up to 120/120 ipm in simplex Up to 240/240 ipm in duplex |
---|---|
Résolution | Up to 600 x 600 dpi |
Modes de numérisation | Scan-to-eMail (Scan-to-Me), Scan-to-SMB (Scan-to-Home) Scan-to-FTP, Scan-to-Box, Scan-to-USB, Scan-to-WebDAV; Scan-to-DPWS, Scan-to-URL; TWAIN scan |
Formats de fichiers | JPEG; TIFF; PDF; compact PDF; encrypted PDF; XPS; compact XPS; PPTX Optional: searchable PDF; PDF/A 1a and 1b; searchable DOCX/PPTX/XLSX |
Destinations | 2,100 (single + group); LDAP support |
Fonctions | Annotation (text/time/date) for PDF; up to 400 job programs; real-time scan preview |
Caractéristiques Copieur
Technologie | Laser |
---|---|
Technologie toner | Simitri® HD polymerised toner/Polymerised toner |
Vitesse copie/impression A4 (N et B / Couleur) | Up to 55/55 |
Vitesse copie/impression A3 (N et B / Couleur) | Up to 27/27 |
Vitesse recto verso A4 (N et B / Couleur) | Up to 55/55 |
Temps de sortie 1ère copie A4 (N et B / Couleur) | 3.5/4.4 sec. |
Temps de préchauffage | Approx. 22 sec. in mono; 22 sec in colour² |
Résolution | 600 x 600 dpi |
Nuances | 256 gradations |
Multicopie | 1-9,999 |
Format | A5-A3; custom sizes |
Taux de zoom | 25-400% in 0.1% steps; auto-zooming |
Fonctions | Chapter; cover and page insertion; proof copy (print and screen); adjustment test print; digital art functions; job setting memory; poster mode; image repeat; overlay (optional); stamping; copy protection |
Caractéristiques Fax
Fax standard | Super G3 (optional) |
---|---|
Transmission | Analogue; i-Fax; Colour i-Fax; IP-Fax |
Résolution | Up to 600 x 600 dpi |
Compression | MH; MR; MMR; JBIG |
Modem | Up to 33.6 Kbps |
Destination | 2,100 (single + group) |
Fonctions | Polling; time shift; PC-Fax; receipt to confidential box; Receipt to e-mail/FTP/SMB; up to 400 job programs |
Caractéristiques Boîtes utilisateurs
Max. stockage de documents | Up to 3,000 documents or 10,000 pages |
---|---|
Type de boites | Public; Personal (with password or authentication); Group (with authentication) |
Système boites | Secure print; Encrypted PDF print; Fax receipt; Fax polling |
Fonctions | Reprint; combination; Download; Sending (e-mail/FTP/SMB and Fax); Copy box to box |
Fonctionnalités système
Sécurité | ISO15408/IEEE 2600.2 compliant (in evaluation); IP filtering and port blocking; SSL2; SSL3 and TSL1.0/1.1/1.2 network communication; IPsec support; IEEE 802.1x support; User authentication; Authentication log; Secure print; Hard disk overwrite (8 standard types); Hard disk data encryption (AES 256); Hard disk mirroring (optional); Memory data auto deletion; Confidential fax receipt; Print user data encryption; Copy protection (Copy Guard, Password Copy) optional |
---|---|
Authentification | Up to 1,000 user accounts; Active Directory support (user name + password + e-mail + smb folder); User function access definition; Biometric authentication (finger vein scanner) optional; ID card authentication (ID card reader) optional; Authentication by mobile device (Android, iOS) |
Logiciels | PageScope Net Care Device Manager; PageScope Data Administrator; PageScope Box Operator; PageScope Direct Print; Print Status Notifier; Driver Packaging Utility; Log Management Utility |
1 If the maximum volume is reached within a period of one year, then a maintenance cycle must be performed
2 Warm-up time may vary depending on the operating environment and usage
- Toutes les caractéristiques se rapportent à du papier A4 de la qualité de 80 g.
- Le support et la disponibilité des caractéristiques et fonctionnalités énoncées dépendent des systèmes d'exploitation, des applications et des protocoles de réseau ainsi que des configurations réseau et système.
- L'espérance de vie des consommables est basée sur des conditions de fonctionnement spécifiques telles qu'une couverture pour une taille de page particulière (couverture de 5% de A4). La durée de vie réelle de chaque consommable varie en fonction de l'utilisation et d'autres variables d'impression, y compris la couverture de page taille, type de support, impression continue ou intermittente, température ambiante et de l'humidité.
- Certaines des illustrations produit contiennent des accessoires en option.
- Les caractéristiques et accessoires sont basés sur les informations disponibles au moment de l'impression et sont sujets à changement sans préavis.
- Develop ne garantit pas que toutes les spécifications mentionnées seront sans erreur.
- Tous les noms de marques et de produits peuvent être des marques déposées ou des marques commerciales de leurs détenteurs respectifs et sont reconnus par les présentes.
